Description
Condition
New open box. Product is New, Packaging will have some cosmetic damage. Sold with full manufacturer’s warranty. Immediate shipment/Collection. VAT invoice provided. NON UK VERSION – 120 V
Specification
OUTPUT
Max Configurable Power (Watts)
280 Watts / 450VA
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz Sync to mains
Topology
Line interactive
Waveform type
Stepped approximation to a sinewave
Transfer Time
4 ms typical : 8 ms maximum
INPUT
Input frequency
50/60 Hz +/- 3 Hz Auto-sensing
Input voltage range for main operations
75 – 154 Adjustable, 82 – 144V
Number of Power Cords
1
BATTERIES & RUNTIME
Battery type
Lead-acid battery
Typical recharge time
5hour(s)
Nominal Battery Voltage
12 V
Replacement Battery
Expected Battery Life (years)
3 – 5
RBC Quantity
1
Battery Charge Power (Watts)
22 Watts
Runtime
Efficiency
COMMUNICATIONS & MANAGEMENT
Interface Port(s)
DB-9 RS-232
Control panel
LED status display with on line : on battery : replace battery and overload indicators
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO)
Optional
SURGE PROTECTION AND FILTERING
Surge energy rating
400Joules
Data Line Protection
RJ11 modem/fax protection (four wire dual line), RJ45 10/100 Base-T Ethernet protection
Filtering
Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449
PHYSICAL
Maximum Height
1.73inches (44MM, 4.4CM)
Maximum Width
17.01inches (432MM, 43.2CM)
Maximum Depth
15.16inches (385MM, 38.5CM)
Net Weight
23.74lbs. (10.77KG)
Shipping weight
27.16lbs. (12.32KG)
Shipping Height
6.46inches (164MM, 16.4CM)
Shipping Width
18.74inches (476MM, 47.6CM)
Shipping Depth
23.19inches (589MM, 58.9CM)
Color
Grey
Units per Pallet
24.0
ENVIRONMENTAL
Operating Temperature
32 – 104 °F (0 – 40 °C)
Operating Relative Humidity
0 – 95 %
Operating Elevation
0 – 10000ft (0 – 3048meters)
Storage Temperature
-15 – 45 °C
Storage Relative Humidity
0 – 95 %
Storage Elevation
0 – 50000ft (0 – 15240meters)
Audible noise at 1 meter from surface of unit
38.0dBA
Online thermal dissipation
38.0BTU/hr
