Description
Item is in “NEW AND UNUSED CONDITION” the original outer packaging will have some cosmetic damage and will have been opened to check contents. Sold with full manufacturer’s warranty. VAT invoice provided.
Hardware Specifications
Model
- MES3500-24
Port Density
- 10/100 FE BASE-T, fixed
- 24
- Dual-personality GbE ports
- 4
Performance
- Switch Capacity (Gbps)
- 12.8
- Switch Forwarding Rate (Mpps)
- 9.6
- Packet Buffer (Bytes)
- 320 K
- MAC Address
- 16 K
Power Requirement
- Input Voltage of AC
- AC Power input (100V~240V)
- Input Voltage of DC
- -37 to -72 V DC
- Maximum Power Consumption (Watt)
- 14
Physical Specifications
- Item
- Dimension (WxDxH) (mm/in.)
- 440 x 200 x 44.5/17.52 x 7.87 x 1.75
- Weight (kg/lb.)
- 2.6/5.73
- Packing
- Dimensions (WxDxH) (mm/in.)
- 495 x 286 x 71/19.48 x 11.26 x 2.8
- Weight (kg/lb.)
- 3.45/7.6
Environmental Specifications
- Operating
- Temperature
- 0°C to 50°C /32°F to 122°F
- Storage
- Humidity
- 10% to 95% (Non-condensing)
- Temperature
- -40°C to 70°C /-40°F to 158°F
Software Specifications
Standard Compliance
- IEEE 802.3 10BASE-T Ethernet
- IEEE 802.3u 100BASE-Tx Ethernet
- IEEE 802.ab 1000BASE-T Ethernet
- IEEE 802.3z 1000BASE-X
- IEEE 802.3x flow control
- IEEE 802.1d spanning tree protocol
- IEEE 802.1w rapid spanning tree protocol
- IEEE 802.1s multiple spanning tree protocol
- IEEE 802.1p class of service, priority protocols
- IEEE 802.1Q VLAN tagging
- IEEE 802.1X port authentication
- IEEE 802.3ad LACP aggregation
- IEEE 802.3az Energy Efficient Ethernet (EEE)
Traffic Management and QoS
- Broadcast storm control
- IEEE 802.1p with 8 hardware priority queues per port for different types of traffic
- IEEE 802.1Q tag-based and port-based VLAN
- Weighted Fair Queuing (WFQ)/WRR/SPQ scheduling algorithm
- Policy based rate limiting
- Policy based bandwidth control
- Port based traffic shaping
- Policy-based traffic mirroring
- IGMP snooping (v1, v2, v3)
- IGMP filtering
- Jumbo frame support (9K Bytes) for high performance data backup or recovery services
- Support GVRP, automatic VLAN member registration
- Multicast VLAN Registration (MVR)
- Q in Q
- Selected Q in Q
Link Aggregation
- IEEE 802.3ad LACP link aggregation compliant
- Support static manually port trunking
- Up to 8 aggregation groups, 8 ports/per group randomly selected
- VLAN trunking
Redundancy for Fault Backup
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) provides rapid convergence of spanning tree independent of spanning-tree timer
- IEEE 802.1s multiple spanning tree provides link availability in multiple VLAN environments by allowing multiple spanning trees
- MRSTP- Multiple RSTP
User Security and Authentication
- IEEE 802.1X authentication
- IP source guard (static IP/MAC binding, DHCP snooping, ARP inspection)
- IP subnet VLAN & VLAN isolation
- Limiting MAC number per port
- Loop guard prevents a switch from being affected by another switch which is already in a looping status
- MAC filtering per port secures access to each port
- MAC freeze
- Port security, port isolation, port mirroring
- Static MAC forwarding per port: only specified MAC addresses can access the network (port security)
- Wire speed filtering per MAC/IP/TCP/UDP
- Wire speed mirroring per MAC/IP/TCP/UDP
- Wire speed rate limiting per MAC/IP/TCP/UDP
- GVRP, automatic VLAN member registration
- Guest VLAN
- CPU protection
- PPPoE option 82
Network Administration Security
- SSH v1/v2
- SSL
- RADIUS accounting
- TACACS+ authentication, accounting
- NTP, daylight saving
IPv6 Host
- IPv6 over Ethernet (RFC 2464)
- IPv6 Addressing Architecture (RFC 4291)
- Dual stack (RFC4213)
- ICMPv6 (RFC4884)
- Path MTU (RFC 1981)
- Minimum Path MTU size of 1280 (RFC 5905)
- Encapsulation for minimum PMTU of 1500
- Neighbor Discovery (RFC4861)
- DHCPv6 Relay/Client
Network Management
- Supports ZyXEL iStacking, up to 24 switches can be managed by one IP address
- Intuitive Web-based management with all features configurable
- Text-based configuration profile for massive deployment
- Telnet CLI (Cisco like)
- SNMP v1, v2c, v3
- SNMP trap group
- RMON four RMON groups 1, 2, 3, 9 (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis
- Out-of-Band management: RS-232c local console
- Firmware upgrade, configuration backup/restore via ftp
- Alarm led indicator for early warning of hardware troubles
- Send system trap to trap server
- DHCP relay, DHCP relay per VLAN, DHCP relay option 82, DHCP client
- Port mirroring: supports source/destination/both port mirroring
- IEEE 802.3ah Ethernet Operations, Administration and Management (OAM)
- sflow
Intelligent ACL (L2/L3/L4 Access List Control)
- Based on port
- Based on MAC + VLAN ID
- Based on IP address (source/destination)
- Based on protocol type
- Based on TCP/UDP port number
MIB Information
- RFC1213 MIB II
- RFC1493 Bridge MIB
- RFC1643 Ethernet MIB
- RFC1757 RMON group 1, 2, 3, 9
- RFC2011 IP MIB
- RFC2012 TCP MIB
- RFC2013 UDP MIB
- RFC2233 ifVHC Packet Group
- RFC2674 VLAN MIB
- RFC2925 PING-MIB and TRACEROUTE-MIB
- ZyXEL private MIB
- Management Information Base (MIB) for IP (RFC4293) (V400)
- IP Forwarding Table MIB (RFC4292) (V400)
- Management Information Base for Transmission Control Protocol (RFC4022) (V400)
- Management Information Base for User Datagram Protocol (RFC4113) (V400)
Safety Agency Certification
- BSMI
- CE
- FCC
- EN 60950-1
- IEC 60950-1
- EU RoHS compliant
